1500T POWER BLADE

Specifications:

Suitable For Laser Receiver 1500R
On Grade LED Green
High/Low LED Red/Yellow
Automatic control Yes, when in auto mode
Out of Beam Indication Yes
Power Option 12 VDC supply through power cable
Operating temprature -20º to 60ºC
Voltage Range 12/24VDC
Electric Output 12/24VDC(5amp. For Each Value)
Hydraulic O/P Settings Directional/Proportional Valves
Water Resistant IP 65
Power On/Off Switch Switch for Automatic and Manual Control Mode Selection
LED Display Show Up-Grade, On Grade and Below Grade position of the Laser Receiver with respect to the Laser Beam
Up/Down Hydraulic switch Manually
